Shimano BR-M8200 -5112 DEORE XT Disc Brake

BR-M8200 -5112 DEORE XT Disc Brake BR Brake - Bremse

Here you will find the spare parts drawing for Shimano BR Brake - Bremse BR-M8200 -5112 DEORE XT Disc Brake. Select the required bicycle spare part from the spare parts list for your Shimano bicycle and simply order online. We always have many Shimano spare parts in stock for you.

Pos	Article Number	Description
1	Y-8JA98010	Flare nut unit Y8JA98010
2	Y-8JA98020	Olive and connecter insert Y8JA98020
3	Y-8H802000	Cover Y8H802000
4	Y-8H198030	TL-BH61 Shimano original tool (2 pcs.) Y8H198030
5	Y-83098040	SM-HANG Hose supporter A and B Y83098040
6	Y-2RT98010	Banjo screw and O-ring Y2RT98010
7	Y-2RT05000	Banjo screw Y2RT05000
8	Y-8SY28000	O-ring Y8SY28000
9	Y-8B214000	Bleed nipple cap Y8B214000
10	Y-8CL98050	Bleed nipple and seal ring Y8CL98050
11	Y-8CL24200	Bleed nipple Y8CL24200
12	Y-8B511001	O-ring for bleed nipple Y8B511001
13	Y-8C509020	Caliper mounting screw (M6 x 18.7) Y8C509020
14	Y-2F398020	Caliper mounting screw (M6 x 18.7) and snap ring Y2F398020
15	Y-2RT06000	Snap ring Y2RT06000
16	Y-8JZ98010	Pad axle and snap retainer Y8JZ98010
17	Y-8JZ05000	Pad axle Y8JZ05000
18	Y-8J716000	Snap retainer Y8J716000
19	E-BPG05ARXA	G05A-RX Resin pad and spring with split pin (pair EBPG05ARXA
20	I-BPG04SMXA	G04S Metal pad and spring with split pin (pair) IBPG04SMXA
21	E-BPJ05ARFA	J05A-RF Resin pad with fin and spring with split pin (pair) EBPJ05ARFA
22	I-BPJ04CMFA	J04C Metal pad with fin and spring with split pin (pair IBPJ04CMFA
23	Y-8DB06100	Split pin Y8DB06100
24	Y-8J709000	Pad spacer Y8J709000
25	Y-8N219000	Bleed spacer Y8N219000
26	I-SMLVOIL01	SM-LVOIL-01 SHIMANO low viscosity oil (100 ml) ISMLVOIL01
26	I-SMLVOIL01M	SM-LVOIL-01 SHIMANO low viscosity oil (100 ml) for EU countries ISMLVOIL01M
26	I-SMLVOIL05	SM-LVOIL-05 SHIMANO low viscosity oil (500 ml) ISMLVOIL05
26	I-SMLVOIL05M	SM-LVOIL-05 SHIMANO low viscosity oil (500 ml) for EU countries ISMLVOIL05M
26	K-SMLVOIL10	SM-LVOIL-10 SHIMANO low viscosity oil (1000 ml) KSMLVOIL10
26	K-SMLVOIL10M	SM-LVOIL-10 SHIMANO low viscosity oil (1000 ml) for EU countries KSMLVOIL10M
27	Y-2RT98020	Caliper mounting screw unit (M6 x 37.9) for SM-MA-F180P/P2 Y2RT98020
27	Y-2RT98030	Caliper mounting screw unit (M6 x 40.2) for SM-MA-F203P/PM Y2RT98030
28	Y-2RT07000	Snap ring A Y2RT07000
29	Y-8G498030	Caliper mounting screw unit (M6 x 32.1) for SM-MA-F180P/P2 A Y8G498030
29	Y-8J498020	Caliper mounting screw unit (M6 x 34.4) for SM-MA-F203P/PM A Y8J498020
30	Y-8JA98026	Connecting insert (100 pcs.) Y8JA98026
31	Y-8H298047	Olive (100 pcs.) Y8H298047
